3 Pin Plugs | NEMA 5-15 Socket (120V), NEMA 6-30, NEMA 6-20 (240V) |
4 pin Plugs
Rating Rated Currents |
NEMA 14-50, NEMA 6-50, NEMA 14-30, NEMA L14-40 (240V)
Indoor/Outdoor rated for installation anywhere 12, 16, 20, 24, 32 and 40 amp |
Weight | 14 pounds |
Connector Type | Type 1 (SAE J1772) lockable. Fits all cars including Tesla with Tesla supplied adapter |
Control Box Dimensions | 2 inches deep x 3.5 inches wide x 8 inches long |
Cable Length | Convenient 25 feet or 32 feet (total charging length from wall socket 26 feet and 34 feet) |
Protection | IP67 (international standard EN 60529) |
Assembly
Temperature |
None
22 degrees Fahrenheit to 140 degrees Fahrenheit |
Warranty | 12 months |
Input voltage | 208-240 Volts alternating current (AC), single phase |
Approvals | CE, CB & TUV Approved |
Material | Premium TPU with thin and lightweight cable |
Compatibility | Suitable for all U.S. and Canadian EVs (SAE J1772 inlet) |
Integrated DC Leakage Protection | Type B residual current detection |
Surge Protection | Over/under voltage, overload protection, short circuit protection, leakage current protection, over
temperature protection, lightning protection, active ground detection |
Ground Monitoring | Yes |
Residual Current Detection | Alternating current 30 milliamps (mA), Direct Current 6 milliamps (mA)
*Requirements of GB 14048.2 – 2008, GB 16916.1-2014 and GB 22794-2008 |
Features | LED indicator lights to manage charging errors |
Kia Soul EV Chargers
Kia Soul EV Chargers
Starting at $275.00
Pick the power level and EV plug type to suit your car. Highest power EV charging for each plug type with delay charging feature until off-peak hours. 100% vehicle compatibility in a complete EV charging solution of EV charger, hanger, cable protector, charging cover, and carry case.
- FlexBox™: Smallest footprint EV charger
- Flexible: Mobile, portable, or mountable wallbox
- Easy to use: Ready to charge. No programming
- Charge Status: Oversized oval green charge light
- Touchscreen: Easy-to-read, digital indicators
- HD: LCD screen and LED control box lights
- Delayed charging: Charge at night during off-peak hours
- Extended length: No cable stretching, driveway parking
- Ready to use: No installation needed – Plug-in, no hardwiring
- All-in-one: Charger, hanger, cable protector, and charger cover
Order Now for Delivery: Sunday, Mar 26! Order in next...
