NEMA 6-50 PLUG Level 2 EV Charger

Starting at $229

image/svg+xml image/svg+xml Layer 1

Choosing the right plug for your home

Make sure the plug type you choose matches the outlet type you have at home. While many outlets look similar, they are definitely not the same. The one called NEMA 5-15 is the regular 120V household outlet that all home appliances use, while other outlet types, such as the 14-50 or 6-50 (The two most popular EV Charging Outlets), get installed specifically for appliances or EV Chargers that require 240V. That said, there are more 240V outlet types that are commonly used, such as the NEMA 14-30, 6-30, 6-20, L14-30, and more.

Do you need a faster charge for your car? Try our NEMA 6-50 Level 2 EV chargers, a high power charging solution for your home or on the go, free shipping included!
Buy Now

This product is out of stock.

Free shipping
Order in the next hrs mins for delivery between 00 and 00!

Feature Icon

Adjustable

Power up or down for your situation

Allows charging on different circuit powers

Delayed charging: Charge at night during off-peak hours

Feature Icon

High Power

Level 2, 220/240-volt charging

Fastest charging for each plug type

High power compatibility with all EVs

Feature Icon

Complete EV Charging Solution

EV Charger

Hanger / Storage

Cable Protector

Charging Cover

Hardshell Carry Case

Feature Icon

Flexibility

Extended length: No cable stretching, driveway parking

Smallest footprint EV charger

Mobile, portable, or mountable wallbox

Ultralight for portable charging

Carry in the trunk or install at home

Feature Icon

Ease of Use

Ready to charge. Plug-in, no programming or hardwiring

Charge Status: Oversized oval green charge light

High Def. LCD screen and LED control box lights

Touchscreen: Easy-to-read, digital indicators

Feature Icon

Safety

Built-in, high sensitivity breaker (RCCB)

Active leak current detection and signal

Pick the power level and EV plug type to suit your car. Highest power EV charging for each plug type with delay charging feature until off-peak hours. 100% vehicle compatibility in a complete EV charging solution of EV charger, hanger, cable protector, charging cover, and carry case.
  • High Power: Level 2, 240 volt charging
  • FlexBox™: Smallest footprint EV charger
  • Flexible: Mobile, portable, or mountable wallbox
  • Easy to use: Ready to charge. No programming
  • Charge Status: Oversized oval green charge light
  • Touchscreen: Easy-to-read, digital indicators
  • HD: LCD screen and LED control box lights
  • Delayed charging: Charge at night during off-peak hours
  • Extended length: No cable stretching, driveway parking
  • Ready to use: No installation needed – Plug-in, no hardwiring
  • All-in-one: Charger, hanger, cable protector, and charger cover
How popular are 6-50 level 2 EV chargers?

They are our second-best-selling EV charger.  Customers typically ask for a 14-50 or 6-50 level 2 EV charger.  6-50 EV Chargers are popular due to the use of this plug type initially by Tesla and other wall box manufacturers.  The NEMA 6-50 plug does not require additional wiring, such as a neutral wire so it is less complex and cheaper to install

6-50 is the electrical standard name given by NEMA (National Electrical Manufacturers Association) to describe a 3-prong 240-volt outlet.  It is a 3-blade receptacle

A NEMA 6-50 at its highest setting will provide up to 40 amps, equivalent to 9.6 kilowatts per hour (kWH) of power to the electric vehicle at a range of 208 to 240 volts depending on local power supply.  Plug-in hybrid vehicles often will not benefit from the 9.6 kilowatts of available power and will generally only accept 3.7, 6.6 or 7.4 kilowatts per hour

A 6-50 will provide around 36 miles of driving range per hour of charging (+/-15% depending on the vehicle, battery life, and temperatures).

There is no major disadvantage compared to a 14-50.  A 6-50 does not have a neutral wire so is cheaper and easier to install but provides less flexibility in the future.

We provide both NACS level 2 EV chargers and J1772 level 2 EV Chargers.  From 2025, most newly produced electric vehicles will be NACS standard.   Ford will transition key models from 2025, whilst Hyundai, Kia, and Genesis will start at the end of 2024.  A NACS connector and a J1772 connector provide the same level of level 2 charging power.

All the major car manufacturers have announced plans to move to a NACS charging port standard from J1772/CCS 1.   Kia, Hyundai, and Genesis will be the first out the gate followed by GM, Ford, Volvo, Nissan, Toyota, and Lexus.

Our NACS EV chargers provide 40amp powerful level 2 EV charging as do our J1772 EV Chargers.

Our AEFA NACS and J1772 EV chargers offer powerful, reliable EV Charging.  Each product is supplied with a suite of useful EV Charging accessories.  The AEFA EV Charger has adjustable power settings, which can help avoid unwanted breaker tripping and each EV Charger is fitted with a built-in breaker for extra safety.

EV Chargers by AEFA - Unboxing
AEFA Quality Control
Car over AEFA charger v2 1
How to Use Our EV Chargers
EV Chargers by AEFA Accessories - Cable Protector
EV Chargers By AEFA Accesories - Hanger
EV Chargers by AEFA Accessories - Protective Cover
Installation video for the hanger reel
AEFA charger working under water
3 Pin Plugs NEMA 5-15 Socket (120V), NEMA 6-30, NEMA 6-20 (240V)
4 pin Plugs

Rating

Rated Currents

NEMA 14-50, NEMA 6-50, NEMA 14-30, NEMA L14-40 (240V)

Indoor/Outdoor rated for installation anywhere

12, 16, 20, 24, 32 and 40 amp

Weight 14 pounds
Connector Type Type 1 (SAE J1772) lockable. Fits all cars including Tesla with Tesla supplied adapter
Control Box Dimensions 2 inches deep x 3.5 inches wide x 8 inches long
Cable Length Convenient 25 feet or 32 feet (total charging length from wall socket 26 feet and 34 feet)
Protection IP67 (international standard EN 60529)
Assembly

Temperature

None

22 degrees Fahrenheit to 140 degrees Fahrenheit

Warranty 12 months
Input voltage 208-240 Volts alternating current (AC), single phase
Approvals CE, CB & TUV Approved
Material Premium TPU with thin and lightweight cable
Compatibility Suitable for all U.S. and Canadian EVs (SAE J1772 inlet)
Integrated DC Leakage Protection Type B residual current detection
Surge Protection Over/under voltage, overload protection, short circuit protection, leakage current protection, over

temperature protection, lightning protection, active ground detection

Ground Monitoring Yes
Residual Current Detection Alternating current 30 milliamps (mA), Direct Current 6 milliamps (mA)

*Requirements of GB 14048.2 – 2008, GB 16916.1-2014 and GB 22794-2008

Features LED indicator lights to manage charging errors
